VMC Performance Boosted with MAZATROL SmoothG Control



Mazak Corporation has enhanced its VTC-200C vertical machining center (VMC) with the addition of the MAZATROL SmoothG CNC and its suite of SMOOTH TECHNOLOGY software solutions. "The control complements the VTC-200C's full traveling-column design, automatic tool changer and powerful 40-taper spindle, all of which combine to enable fast cycle times and accurate machining for long and heavy workpieces in industries such as construction, agriculture and energy production," said a company spokesperson.

"Job shops and major manufacturers alike will benefit from the VTC-200C's new MAZATROL SmoothG CNC and its innovative programming, performance and monitoring functions, as well as the ability to use both EIA/ISO and conversational programming to bring optimum speed and accuracy to complex part production," added the spokesperson. Advanced hardware-including a pivoting CNC panel and intuitive, 19" multi-touch LCD control screen-allows for ease of use, while a CFast memory card stores up to 32 GB of program data.

The VTC-200C machine platform features a standard 15,000 RPM, 30 HP (10% ED, 110 Nm) spindle capable of handling a wide variety of metalcutting applications. The machine rapid traverses in all axes at a rate of 1,574 IPM, while its standard integration of Intelligent Thermal Shield (ITS) software helps maintain machine accuracy in a wide range of factory environments.

The machine's fixed 78.74" by 20" table is designed to provide process flexibility for a wide range of applications, and its optional center partition can divide the work envelope into two separate work areas to allow the machine to be in cycle in one area while operators load, unload or set up a part in the other. The machine's axis travels measure 65.35" in X, 20" in Y and 20" in Z.

For further process flexibility, manufacturers can double the standard 24-tool automatic tool changer's capacity with an optional 48-tool magazine or upgrade to a 50 HP, 20,000 RPM integral spindle.

The VTC-200C can integrate with a variety of robotically loaded solutions provided by Mazak Automation Systems, and its new SmoothG control makes it easy to take advantage of machine monitoring software such as SMOOTH Link and IIoT connectivity tools such as MTConnect and the Mazak SmartBox.
