Master Tap Product Line Expanded

The Hoffmann Group has expanded its GARANT Master Tap product range to include additional high-performance taps for reliable thread tapping in stainless and high-alloy steels.

The GARANT Master Tap INOX tap is now available for thread diameters from M1.6 to M24 and with longer lengths for increased reach. It is also available for UNC and UNF inch diameters from No. 2 to 1" standards in addition to the thread standards M, MF and G (BSPP). These new tools are available now from the eShop at hoffmann-group.com and can be ordered using the 2020/2021 catalog.

The GARANT Master Tap INOX is suitable for producing through and blind hole threads with a tolerance of 6GX. "It provides top process reliability and performance capability along with a long working life due to a special cutting edge geometry that provides evenly turned chips that are ejected in a targeted way due to the optimized flutes," said a company spokesperson. The backs of the teeth are specially designed to shear off the chips, polish the chip roots and prevent loose or twisted swarf from forming.

The cutting edges of the GARANT Master Tap INOX have also been rounded off to help ensure reliable thread machining in stainless and high-alloy steels. As a result, the teeth resist fracture and the tool wears evenly. A wear-resistant HSS-E-PM tool material and low-friction TiAIN multi-layer anti-friction layer protect against premature wear.

"With the expanded product range, there are now even more tools available to professional users for reliable thread machining in stainless and acid-resistant steels," said the spokesperson. "Users that also often want to machine materials such as different steels, aluminum, brass and cast iron can alternatively make use of the GARANT Master Tap general-purpose tap. It achieves precise results, even in ductile copper alloys, without any axial overcutting and makes frequent tool changes redundant."

For more information contact:

Hoffmann Group USA

202 N. Seven Oaks Drive

Knoxville, TN 37922

844-448-7725

sales.usa@hoffmann-group.com

www.hoffmanngroupusa.com
