Technological Advancement in Video Comparator Systems



Optical Gaging Products (OGP) has announced a technological breakthrough in value-class video comparator systems: The Automatic Three-Position Lens Changer, available on c-vision Lite Video Contour Projectors.

This CNC lens turret allows for nine automatic, programmable magnification changes-three optical and six digital-within a CNC program. The system is both parfocal and parcentral-parts on the stage stay in focus and stay centered when magnification and focal length is changed.

Three internal lenses offer 2", 1" and 1/2" fields of view and are permanently mounted in a shop-hardened motorized turret.

"Before this innovation, operators were required to manually unscrew a lens, attempt to safely store the lens, screw in a new lens and recalibrate-a very timely task that could never be done in the middle of a program," said Tim Fantauzzo, OGP Vice President of North American Sales. "The innovative c-vision Lite lens turret system allows for these changes automatically, and as part of a CNC program, resulting in far faster and more accurate measurement results-tying together small part feature details with larger overall part measurements."

For more information contact:

Optical Gaging Products (OGP)

850 Hudson Avenue

Rochester, NY 14621

585-544-0400

800-647-4243

sales@ogpnet.com

www.ogpnet.com/c-vision
