Laser Software Delivers On-The-Fly Alignment Data Analysis
April 1, 2014
Pinpoint Laser Systems has introduced a new and improved data accessory named "Pinpoint Capture" for the Laser Microgage industrial measuring and alignment system. Pinpoint Capture allows operators to quickly grab measurement readings, on the fly, from as many as four remote laser receivers to analyze the alignment and performance of their production machinery and industrial equipment. "The software is a powerful, Windows-based application that quickly records incoming readings, displays results and enables added control. It interfaces cleanly with spreadsheets, statistical analysis packages and other programs. Capture allows measurement readings to be stored directly in the handheld, portable Laser Microgage display and then uploaded to a PC or laptop or routed directly to the PC or laptop for analysis, printing and storage. The Laser Microgage armed with the new Capture software is easy to use and highly versatile, delivering a precision of 0.0001 inch (0.0025 mm) over a working range of 180 feet (55 meters)," said a company spokesperson.
The new Pinpoint Capture software brings new capabilities to industrial alignment and measuring. The program collects and displays measuring readings from up to four laser receivers placed on machinery. These displays can be customized for specific user alignment and measuring applications. A built in spreadsheet function allows for easy computations on incoming readings and additional graphing and plotting capabilities. A step-by-step instruction feature gives users an active recipe to follow for popular alignment routines on industrial machinery. Pinpoint Laser Systems has also installed standard measurement and alignment routines that are versatile, quick and easy to follow for general alignment tasks such as spindle and lathe alignment, machine tool runout checks and other common applications. Laser Microgage measurements can be stored automatically with many readings per second or can be recorded over time individually by the user with notes.
Pinpoint's Laser Microgage System is used across many industries for checking the alignment of production machinery and equipment. The precise laser reference beam is intended for checking straightness, flatness, squareness, parallelism, bore alignment and many other geometrical parameters. Pinpoint products are designed and manufactured in the U.S. and incorporate durable, solid metal packaging, stainless steel components and quality glass optics. A wide assortment of accessories enables users to adapt their Laser Microgage to new applications and reduce their dependence on outside alignment contractors.
For more information contact:
Pinpoint Laser Systems
56 Pulaski Street #5
Peabody, MA 01960
800-757-5383 / 978-532-8001
info@pinpointlaser.com
www.pinpointlaser.com
