Online Access to 2D and 3D Tooling Data

BIG KAISER has redesigned one of the most popular tools on the manuals, DXF and STEP (STP) Search. The improvements make finding 2D and 3D data and specific product manuals easier. As users type a catalog number into the search field, a drop-down menu will display available DXF, STP and manuals.

"After gathering feedback from our customers, the tool was completely redesigned for the North American market," said Alan Miller, Engineering Manager. "The hope is that making both DXF and STP models available online will help customers work a little faster and make their day-to-day jobs easier."

DXF standard allows customers to combine products from multiple companies with unified layer structures. The STP standard keeps things simple for program simulation. DXF access is open to anyone, but STP downloads will require a log-in (application link on download page).

The tool can be found at

For more information contact:


2600 Huntington Blvd.

Hoffman Estates, IL

888-866-5776 / 224-770-2999
